MAIN TECHNICAL DATA
Power:0.5～30VA
Degree of Protection:IP00
Primary: 110/230V 50/60Hz
Secondary: 12/24VAC
Insulation class:Class A、Class B
Insulation:3.75KV Rms
Ambient temp: (t)-40℃
Standards compliant:
EN61558-2-6/ UL5085-1/UL5085-2/UL5085-3/UL1446
Schematics：
Structure diagram：
Dimensions(mm)
|
Power/VA |
A |
B |
C |
D |
E |
F |
Weight/kg |
|
1.5VA |
28.5 |
20.0 |
27.0 |
2P×14.6 |
5P×3.65 |
20.5 |
0.06 |
|
2.5VA |
28.5 |
20.0 |
33.6 |
3P×7.6 |
4P×3.6 |
19.2 |
0.09 |
|
2.0VA |
35.5 |
30.0 |
30.5 |
3P×7.4 |
4P×5.0 |
20.5 |
0.10 |
|
2.5VA |
35.5 |
30 |
36.0 |
5P×4.8 |
5P×4.8 |
21.0 |
0.13 |
|
3.5VA |
35.5 |
30.5 |
38.0 |
2P×19.6 |
5P×4.9 |
21.7 |
0.16 |
|
4.5VA |
41.5 |
33.5 |
32.0 |
2P×26.5 |
7P×4.4 |
25.8 |
0.17 |
|
4.5VA |
41.5 |
33.5 |
40.0 |
4P×7.7 |
5P×5.8 |
23.2 |
0.19 |
|
5.0VA |
41.5 |
33.5 |
38.0 |
2P×26.5 |
7P×4.4 |
25.8 |
0.21 |
|
5.5VA |
41.5 |
33.5 |
43.0 |
4P×7.4 |
8P×5.0 |
23.5 |
0.23 |
|
5.0VA |
48.5 |
33.5 |
20.0 |
7P×5.0 |
7P×5.0 |
25.8 |
0.19 |
|
7.0VA |
48.5 |
40.5 |
37.0 |
5P×7.4 |
5P×7.4 |
29.5 |
0.24 |
|
9.0VA |
48.5 |
40.5 |
41.5 |
5P×7.4 |
6P×5.0 |
29.5 |
0.31 |
|
10.0VA |
48.5 |
40.5 |
43.0 |
5P×7.5 |
5P×7.5 |
29.5 |
0.34 |
|
14.0VA |
48.5 |
40.5 |
46.0 |
5P×7.4 |
5P×7.4 |
29.5 |
0.43 |
|
20.0VA |
57.5 |
50.5 |
51.0 |
7P×5.0 |
7P×5.0 |
32.0 |
0.65 |
|
20.0VA |
66.5 |
55.5 |
48.0 |
9P×5.0 |
9P×5.0 |
38.5 |
0.69 |
Customer Design Avaiable
